Product Description
12U 300mm cabinet: wall or floor mount, lockable glass front
A 12U enclosure with 300mm depth suits patch panels, small switches, NVRs and CCTV head-end kit where floor space is tight and full-depth server cabinets aren't justified.
Key specs
- External dimensions: 30cm (W) x 30cm (D) x 61cm (H)
- Mounting: wall or floor mounted
- Front door: lockable tempered glass — visual check on equipment status without opening the cabinet
- Rack rails: adjustable 19-inch rails, accommodating varying equipment sizes
- Side panels: removable, for access to installed kit
- Ventilation: front and side vent slots plus a vented rear panel for airflow
- Cable entry: top and bottom panel entry points for cable management
- Construction: steel body, black coated finish
- SKU: CABINET-12U-300 (also listed as GR-CABINET-12U-300-LN)
Fit on the job
12U at 300mm depth is a shallow-cabinet spec — fine for patch panels, PoE switches and NVR/DVR units, but check chassis depth on anything with deep power supplies or rear cabling before specifying. The 19-inch rail spacing is adjustable, so mixed equipment depths within the 12U height can be accommodated on the same install.
Removable side panels and dual top/bottom cable entry keep first-fix cable runs tidy in comms cupboards or small equipment rooms, whether the cabinet ends up wall-hung or floor-standing.
Specifications
- Width
- 30cm
- Depth
- 30cm
- Height
- 61cm
Technical Specifications
Frequently Asked Questions
What are the external dimensions of the 12U-300 cabinet?
30cm wide x 30cm deep x 61cm high, per the 12U-300 spec.
Can this cabinet be wall mounted or does it need floor standing?
Both are supported — it's designed for wall or floor mounting.
Does the door allow visual inspection of equipment when locked?
Yes, the front door is tempered glass and lockable, so equipment status is visible without opening it.
Is 300mm depth enough for network switches and NVRs?
It suits patch panels, small switches and NVR/DVR units, but check the depth of your specific equipment against the 300mm cabinet depth before ordering.
