Product Description
SPL-2-8 is a 2-in/8-out lever wire connector for splicing one feed to multiple runs from a single wiring point. On CCTV jobs this covers PSU distribution to several camera drops, junction-box splicing, or lighting-circuit tees where one supply needs to reach multiple conductors.
Key specs
- 2 input terminals, 8 output terminals — one source feeds up to eight outgoing conductors
- Tool-free lever-lock clamping — no screwdriver, crimp tool or solder required; lift the lever, insert the stripped conductor, press down to lock
- Reusable — levers release cleanly, so runs can be added or re-terminated without cutting back cable
- Accepts solid, stranded and flexible conductors
- Flame-retardant insulated housing with internal metal contacts for stable conductivity
Where it fits on a job
Compact enough for junction boxes, lighting fixtures, electrical enclosures and control panels where several cables converge. On CCTV installs, that's typically inside a camera back-box or distribution enclosure where a single low-voltage feed needs splitting across multiple device drops, or where an installer is tidying a multi-run junction without carrying crimps or a soldering iron on the ladder.
The lever mechanism speeds up first-fix wiring and simplifies snagging — if a run needs moving, the connector releases and reconnects without replacing the terminal.
Specifications
- Model
- SPL-2-8-2
- Product Type
- Lever wire connector / splicing terminal
- Input Terminals
- 2
- Output Terminals
- 8
Frequently Asked Questions
How many conductors can the SPL-2-8 connect?
It has 2 input terminals and 8 output terminals, so one feed can be distributed to eight separate outgoing conductors.
Do I need tools to use the SPL-2-8?
No — it uses a tool-free lever-lock system: lift the lever, insert the stripped conductor and press down to lock.
What conductor types does it accept?
It's suitable for solid, stranded and flexible conductors.
Can the connector be reused if I need to change the wiring?
Yes, it's a reusable connector designed for fast wiring changes without cutting back cable.
