What's in the box
Every part in this kit and how many of each you get. Tap a part to see its full specification.
4 cameras included, keeps about 11 days of footage, uses analogue cameras; check existing coax cable condition and compatibility before reuse.
Recorder capacity
4 included cameras use 4 of the recorder’s 4 channels. All stated channels are occupied. A larger system needs a recorder with additional capacity.
Recording storage
2TB storage is included. Estimated recording time: about 11 days with continuous H.265 recording. The estimate uses 2 Mbps per camera up to 2MP, 4 Mbps up to 5MP and 8 Mbps above 5MP, summed for mixed camera models. Actual retention depends on settings, scene activity and usable drive capacity; motion-only recording varies with activity.
Before installation
Check the component list below for included cables, power supplies and mounting accessories. Choose cable lengths and camera positions for your layout; camera count alone does not establish coverage. Confirm lens field of view, lighting and weather protection for each position.
Price on request
One part of this kit — the Seagate 2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording — is sold at a quoted price, so we price the kit for you rather than publish a total. Everything else in the box is listed below.
The recorder
XVR-3104HS-5MP-LITE 4-Channel 5MP Lite Digital Video Recorder
The box that saves everything and runs the app
The cameras× 4
Hikvision 5 MP Audio Fixed Turret Camera
What goes on the wall
The hard drive
Seagate 2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording
Where the footage is kept
The power supply
12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
One plug that powers the cameras
The cable× 4
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 4-channel HD-over-coax CCTV kit built on the XVR-3104HS-5MP-LITE + 4× Hikvision DS-2CE78H0T-IT3FS. 4 cameras at 5MP — sized for a house or flat. The included 2TB hard drive holds about 11 days of continuous recording — the estimate assumes recording all 4 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× XVR-3104HS-5MP-LITE 4-Channel 5MP Lite Digital Video Recorder; 4× Hikvision 5 MP Audio Fixed Turret Camera; 1× Seagate 2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug.
Specifications
- System type
- Analog (HD over coax)
- Built on
- XVR-3104HS-5MP-LITE + 4× Hikvision DS-2CE78H0T-IT3FS
- Recorder
- 4-channel XVR-3104HS-5MP-LITE 4-Channel 5MP Lite Digital Video Recorder
- Cameras included
- 4× Hikvision 5 MP Audio Fixed Turret Camera
- Camera resolution
- 5MP
- Storage
- 2TB HDD — about 11 days of footage, recording all 4 cameras continuously at high quality (H.265)
- Cables & PSU included
- 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- What's in the box
- 1× XVR-3104HS-5MP-LITE 4-Channel 5MP Lite Digital Video Recorder; 4× Hikvision 5 MP Audio Fixed Turret Camera; 1× Seagate 2TB - HDD 3.5" SATA Hard Drives – Free Installation with Any CCTV Kit or Package -Ideal for 24/7 continuous recording; 4× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 3A CCTV Power Supply Adapter 4 Way Splitter UK Plug
