Hikvision 16-Channel 2MP – 5MP CCTV Kit — 2 DS-2CE78K0T-LTS 5MP Turret + 5 White HDT-2MP-N20W-2.8MM 2MP Dome Cameras + 6TB Recording (XVR-3116HS-5MP-LITE Recorder)
SKU: KIT-HD16-XVR3116HS5MP-DS2CE78K0TLTX07-6TB-TBAR1Copied!
Built on: XVR-3116HS-5MP-LITE + 2× Hikvision DS-2CE78K0T-LTS + 5× HDT-2MP-N20W-2.8MM. Keeps about 30 days of continuous footage on the included 6TB surveillance hard drive.
Low Stock
Only 6 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a shop or small business — 7 cameras, keeps about 30 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR)
The box that saves everything and runs the app
The cameras× 2
Hikvision 3K Two Way Audio Fixed Turret
What goes on the wall
The cameras× 5
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The hard drive
Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 7
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 16-channel HD-over-coax CCTV kit built on the XVR-3116HS-5MP-LITE + 2× Hikvision DS-2CE78K0T-LTS + 5× HDT-2MP-N20W-2.8MM. 7 cameras at 2MP + 5MP — sized for a shop or small office. The included 6TB surveillance hard drive holds about 30 days of continuous recording — the estimate assumes recording all 7 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR); 2× Hikvision 3K Two Way Audio Fixed Turret; 5× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed.
Specifications
- System type
- Analog (HD over coax)
- Built on
- XVR-3116HS-5MP-LITE + 2× Hikvision DS-2CE78K0T-LTS + 5× HDT-2MP-N20W-2.8MM
- Recorder
- 16-channel Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR)
- Cameras included
- 2× Hikvision 3K Two Way Audio Fixed Turret; 5× 2MP HD 4in1 Dome Camera (2.8mm/ White)
- Camera resolution
- 2MP + 5MP
- Storage
- 6TB surveillance HDD — about 30 days of footage, recording all 7 cameras continuously at high quality (H.265) — the load is 2× 5MP + 5× 2MP
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- What's in the box
- 1× Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR); 2× Hikvision 3K Two Way Audio Fixed Turret; 5× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
