AX PRO INTRUDER DETECTION, WIRELESS DETECTORS
SKU: DS-PDMC-EG2-WE(B)Copied!
AX PRO Series Wireless Magnetic Contact, wireless door/window opening detector, configurable through App, 5 years replaceable battery life span, 2 year warranty
Low Stock
Only 2 left - order soon!
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
Product Description
AX PRO Wireless Magnetic Contact — DS-PDMC-EG2-WE(B)
The DS-PDMC-EG2-WE(B) is a wireless door/window contact from the AX PRO intruder detection range, intended for wireless zone coverage on AX PRO panels.
Key specs
- Type: wireless magnetic contact (opening detector) — reed switch triggered by a separate magnet unit on the door/window leaf.
- Configuration: set up and configured via app, so zone naming, sensitivity and testing can be done without opening the panel enclosure.
- Battery life: rated for 5 years, and the battery is replaceable rather than sealed, so the unit doesn't need to be scrapped at end of battery life.
- Warranty: 2 years.
Installer notes
On a wireless install this contact removes the need to run a cable to the door/window leaf, which is the usual reason for choosing it over a wired contact on retrofits or on doors that flex. Because configuration is app-based, technicians can commission and test the zone from the panel's companion app rather than relying purely on physical DIP switches, which speeds up multi-door commissioning on larger AX PRO jobs.
No mounting dimensions, RF range, wireless protocol or specific panel compatibility list is given in the available documentation for this SKU — confirm these against the AX PRO panel's own compatibility notes before specifying on a job where RF range or exact panel firmware matters.
Specifications
- Detection Method
- Opening Contact
- Detection Gap
- 43 mm Max
- Digital Processing
- Support
- Tamper Protection
- Front,Rear
- Alarm Input
- Normally Closed,Normally Open,Impulse Count
- Power Switch
- Power up enrolling
- Transmission Technology
- Tri-X Wireless
- Transmission Method
- Two-Way RF Wireless
- Transmission Frequency
- 868MHz
- Transmission Security
- AES-128 Encryption
- Transmission Range(Free Space)
- 1.6Km
- Frequency Hopping
- Support
- Enrolling Method
- Power up,Remote ID,QR Code
- Standard Battery Life
- Up to 5 years (standby time)
- Power Supply
- Battery powered
- Battery Type
- CR123A x 1
- Typical Voltage
- 3V
- Operation Temperature
- -10°C to 55°C (14°F to 131°F)
- Storage Temperature
- -20°C to 60°C (-4°F to 140°F)
- Operation Humidity
- 10% to 90%
- Weight
- 59 g
- Application Scenario
- Indoor
- DS-PWA96-Kit2-WE
- DS-PDB-MC-Brown
Technical Specifications
Frequently Asked Questions
How is the DS-PDMC-EG2-WE(B) configured?
It's configured through an app rather than only via physical switches, so installers can set up and test the wireless zone from the panel's companion app.
What is the battery life on this contact?
It's rated for 5 years and the battery is replaceable, so the whole unit doesn't need replacing when the battery runs down.
Does this contact need wiring to the door or window?
No — it's a wireless magnetic contact, so no cable run is needed to the door/window leaf, only the panel needs to be within wireless range.
What warranty applies to the DS-PDMC-EG2-WE(B)?
It carries a 2 year warranty.
