Product Description
ACM-K6B Exit Push Button — DC12V Stainless Steel
A wired exit release button for access control panels, built into a stainless steel housing. Model ACM-K6B, DC12V input, 86mm x 86mm faceplate.
Key specs
- Input: DC12V
- Dimensions: 86L x 86W (mm)
- Output contact: NO/NC/COM — wire to whichever the controller expects
- Detection range: 0.1–10cm
- Operating temperature: -20°C to +55°C (14–131°F)
- Humidity: 0-95% relative humidity
- Weight: 0.15kg
- Suitable for door type: Hollow door
Fitting notes
The NO/NC/COM output contact lets it terminate to either a normally-open or normally-closed input on the access control panel, giving flexibility on wiring logic during a first-fix install.
The -20°C to +55°C operating range and 0-95% humidity tolerance are the manufacturer's stated environmental limits for the unit, alongside its 0.1-10cm detection range, provided the door itself is a hollow-door type as specified. No current draw or power-budget figures are given, so confirm panel loading separately when planning multi-door supply runs.
At 0.15kg, the ACM-K6B is a lightweight, DC12V-input component intended for wired access control setups.
Application: gate, door, exit and automation control wiring for access systems where a physical push-to-exit point is required alongside card or keypad entry.
Specifications
- Dimensions
- 86Lx86W(mm)
- Weight
- 0.15kg
Technical Specifications
Frequently Asked Questions
What voltage does the ACM-K6B run on?
It takes a DC12V input.
What output contact options does it have?
It provides NO/NC/COM contacts, so it can be wired to a normally-open or normally-closed panel input.
What door type is the ACM-K6B rated for?
It's specified as suitable for hollow doors.
What's the operating temperature range?
-20°C to +55°C (14-131°F), with 0-95% relative humidity tolerance.
