Product Description
The Western Digital WD160EDFZ 16TB 3.5in SATA Internal HDD (SKU HDD-16TB-Western-Digital-R) is a 5400 RPM class drive for recorders and storage builds where capacity matters more than sustained write throughput.
Key specs
- Capacity: 16TB
- Form factor: 3.5-inch internal
- Interface: SATA III, 6Gb/s
- Spindle speed: 5400 RPM class, aimed at lower power draw, lower acoustic output and better thermal behaviour in enclosed units
- Format: Advanced Format (AF) 4K sectors
- Supply: OEM, internal-use labelled
- RAID: supports RAID configurations for basic redundancy
Where it fits on a job
Suitable for light to moderate NVR/DVR systems, small to medium CCTV installations, NAS units, archive and backup. It is specified for continuous operation in enclosed systems handling moderate workloads.
Where it doesn't
This is not a dedicated surveillance-grade or enterprise drive. It suits controlled workload environments rather than heavy, sustained write duty. For high channel counts or demanding recording profiles, specify a drive built for that duty.
Check that the recorder accepts AF 4K-sector drives and a 16TB capacity before ordering. Capacity limits differ by recorder model.
Specifications
- Brand
- Western Digital
- Capacity
- 16TB
- Connector Type
- SATA
Technical Specifications
Frequently Asked Questions
Is the WD160EDFZ a surveillance-specific drive?
No. It is not a dedicated surveillance-grade or enterprise drive, and is best suited to light to moderate NVR/DVR use and controlled workloads.
What interface does the WD160EDFZ use?
SATA III at 6Gb/s, in a 3.5-inch internal form factor.
Can it be used in a RAID setup?
Yes, it supports RAID configurations for basic redundancy and storage management.
