Product Description
Overview
An 86" 4K UHD interactive touch panel for integrators fitting out meeting rooms, training suites and classrooms where multiple users need to share and annotate content on one display.
Key specs
- Panel: 86" IPS D-LED, 3840 × 2160 (4K UHD), 400 cd/m² brightness
- Touch: 20-point multi-touch via infrared touch technology
- OS: Android 13, onboard applications, no external player required for basic use
- Audio: 2 × 18W integrated stereo speakers
- Wireless sharing: NovoConnect Lite for screen mirroring without HDMI cabling
- Whiteboard: integrated digital whiteboard for annotation over shared content
- Connectivity: HDMI 2.0, USB-C, USB-A, LAN, RS232 for AV and room-control integration
- Mounting: VESA-compatible for wall mounts or floor stands
Deployment notes
For system integrators, the RS232 and LAN ports allow the panel to sit on room-control networks alongside other AV infrastructure rather than running as a standalone display. HDMI 2.0 covers standard 4K source connections, while USB-C adds single-cable video and data for laptops that support it.
The 20-point touch ceiling matters on collaborative jobs — design reviews, joint client presentations, training rooms — where more than one person is expected to interact with the screen simultaneously. Android 13 with onboard apps means the panel can run scheduling, signage or presentation content without a connected PC, which simplifies commissioning on jobs where a dedicated media player isn't in scope.
Also listed under the part number PDI-086I BKVEN0 — worth checking against this if cross-referencing against another supplier's stock sheet or a prior spec.
Specifications
- Screen Size
- 86"
- Resolution
- 3840 × 2160
Technical Specifications
Frequently Asked Questions
What resolution does the NovoTouch 86" support?
It's a 4K UHD panel running at 3840 × 2160 on an IPS D-LED screen rated at 400 cd/m² brightness.
How many simultaneous touch points does it handle?
The infrared touch system supports up to 20 simultaneous touch points, suiting multi-user annotation and collaboration.
Can it be used without a separate PC?
Yes — it runs Android 13 with onboard applications, so it can operate standalone for presentations or signage.
What control and connectivity options are available for integration?
It has HDMI 2.0, USB-C, USB-A, LAN and RS232, allowing it to be wired into AV systems and room-control networks, and it supports VESA mounting.
