Hikvision 32-Channel 2MP – 5MP CCTV Kit — 1 5MP Turret + 4 2MP Dome Cameras + 4TB Recording
SKU: KIT-HD32-IDS7232HQHIM-DS2CE71H0TPIX05-4TB-U1U78Copied!
Built on: Hikvision iDS-7232HQHI-M2/XT + 1× Hikvision DS-2CE71H0T-PIRLO + 4× HDT-2MP-N20W-2.8MM. Keeps about 30 days of continuous footage on the included 4TB surveillance hard drive.
Low Stock
Only 6 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
What's in the box
Every part in this kit and how many of each you get. Tap a part to see its full specification.
Enough for a shop or small business — 5 cameras, keeps about 30 days of footage, it reuses the round coax cable an older system left behind.
Price on request
One part of this kit — the Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM — is sold at a quoted price, so we price the kit for you rather than publish a total. Everything else in the box is listed below.
The recorder
Hikvision 32-ch 5MP1U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras
Hikvision 5 MP PIR Fixed Turret Camera
What goes on the wall
The cameras× 4
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The hard drive
Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 5
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision iDS-7232HQHI-M2/XT + 1× Hikvision DS-2CE71H0T-PIRLO + 4× HDT-2MP-N20W-2.8MM. 5 cameras at 2MP + 5MP — sized for a shop or small office. The included 4TB surveillance hard drive holds about 30 days of continuous recording — the estimate assumes recording all 5 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 5MP1U H.265 AcuSense DVR; 1× Hikvision 5 MP PIR Fixed Turret Camera; 4× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision iDS-7232HQHI-M2/XT + 1× Hikvision DS-2CE71H0T-PIRLO + 4× HDT-2MP-N20W-2.8MM
- Recorder
- 32-channel Hikvision 32-ch 5MP1U H.265 AcuSense DVR
- Cameras included
- 1× Hikvision 5 MP PIR Fixed Turret Camera; 4× 2MP HD 4in1 Dome Camera (2.8mm/ White)
- Camera resolution
- 2MP + 5MP
- Storage
- 4TB surveillance HDD — about 30 days of footage, recording all 5 cameras continuously at high quality (H.265) — the load is 1× 5MP + 4× 2MP
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 5MP1U H.265 AcuSense DVR; 1× Hikvision 5 MP PIR Fixed Turret Camera; 4× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Toshiba S300 4TB Surveillance Hard Drive 3.5" SATA 5400RPM; 5× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
