Product Description
UK-MAGLOCK-DOUBLE-1000KG is a dual-magnet electromagnetic lock rated at a combined 1000kg holding force, built for double-door access control installations.
Configuration
The unit houses what is typically two 500kg magnetic locks within a single surface-mount body, giving one holding-force rating per leaf across a double-door opening. This is the key spec to check against door schedules on commercial jobs — offices, warehouses, apartment blocks and other multi-occupancy or restricted-access sites.
Power and control
- Dual voltage: 12V DC or 24V DC, selectable to suit the site's existing access control power supply
- Fail-safe operation — the lock releases on power interruption, so it should be specified with an access controller, keypad, push-to-exit button or emergency release device that can cut power on demand
- Integrates with card readers, biometric readers, intercom door entry panels and standard access controllers
Mounting and door types
Surface-mounted above the double-door frame, with armature plates supplied for fixing to the door leaf. Rated for use on wooden, metal, glass and fire-rated doors, provided the appropriate mounting brackets for the door type are used.
Fail-safe vs fire doors
Because this is a fail-safe lock, it releases on loss of power — a property that matters when specifying against fire door and emergency egress requirements on a given installation.
Frequently Asked Questions
What is the holding force of the UK-MAGLOCK-DOUBLE-1000KG?
It provides a combined 1000kg holding force, typically made up of two 500kg magnetic locks housed in a single unit, one per door leaf on a double-door opening.
Is this lock fail-safe or fail-secure?
It is fail-safe: the magnetic field releases when power is interrupted by an access controller, keypad, push-to-exit button or emergency release device, allowing the door to open.
What voltage does it run on?
It supports dual voltage operation at either 12V DC or 24V DC, so it can be matched to common access control power supplies.
What door types can it be fitted to?
It is suitable for wooden, metal, glass and fire-rated doors when installed with the appropriate mounting brackets, and is fitted as a surface-mount unit above the double-door frame with the supplied armature plates.
