Hikvision 16-Channel 2MP – 5MP CCTV Kit — 1 DS-2AE4225T 2MP PTZ + 8 DS-2CE12KF3T 5MP Bullet Cameras + 14TB Recording
SKU: KIT-HD16-IDS7216HUHIM-DS2AE4225TADX09-14TB-DO7UZCopied!
Built on: Hikvision iDS-7216HUHI-M2/XT + 1× Hikvision DS-2AE4225T-A + 8× Hikvision DS-2CE12KF3T-PIRXO. Keeps about 38 days of continuous footage on the included 14TB hard drive.
Low Stock
Only 10 left - order soon!
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a large property or yard — 9 cameras, keeps about 38 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 16-ch 8 MP 1U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras
Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome
What goes on the wall
The cameras× 8
HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
What goes on the wall
The hard drive
Toshiba MG07ACA14TE 14TB 3.5" SATA III Enterprise HDD 7200RPM
Where the footage is kept
The power supply
18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit
One plug that powers the cameras
The cable× 9
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 16-channel HD-over-coax CCTV kit built on the Hikvision iDS-7216HUHI-M2/XT + 1× Hikvision DS-2AE4225T-A + 8× Hikvision DS-2CE12KF3T-PIRXO. 9 cameras at 2MP + 5MP — sized for a larger property or yard. The included 14TB hard drive holds about 38 days of continuous recording — the estimate assumes recording all 9 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 9× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 16-ch 8 MP 1U H.265 AcuSense DVR; 1× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 8× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 1× Toshiba MG07ACA14TE 14TB 3.5" SATA III Enterprise HDD 7200RPM; 9× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision iDS-7216HUHI-M2/XT + 1× Hikvision DS-2AE4225T-A + 8× Hikvision DS-2CE12KF3T-PIRXO
- Recorder
- 16-channel Hikvision 16-ch 8 MP 1U H.265 AcuSense DVR
- Cameras included
- 1× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 8× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
- Camera resolution
- 2MP + 5MP
- Storage
- 14TB HDD — about 38 days of footage, recording all 9 cameras continuously at high quality (H.265) — the load is 1× 2MP + 8× 5MP
- Cables & PSU included
- 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit; 9× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 16-ch 8 MP 1U H.265 AcuSense DVR; 1× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 8× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 1× Toshiba MG07ACA14TE 14TB 3.5" SATA III Enterprise HDD 7200RPM; 9× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit
