Prolux PXD-8204-HYK4MP 4CH Hybrid DVR 4MP Lite H.265 CCTV Recorder

The Prolux PXD-8204-HYK4MP is a 4 channel hybrid digital video recorder (DVR) designed for analogue HD CCTV surveillance systems. The recorder supports multiple camera technologies including HD-TVI, AHD, CVI and CVBS, allowing it to be integrated into a wide range of security installations.

The DVR supports recording resolutions up to 4MP Lite, providing higher image detail compared with standard 1080p systems. When 1080p Lite mode is disabled, the system supports recording resolutions including 4MP Lite, 3MP, 1080p, 720p, WD1, VGA and CIF. When 1080p Lite mode is enabled, the system supports 4MP Lite, 3MP, 1080p Lite and 720p Lite recording modes.

The main stream supports 4MP Lite recording at up to 15 frames per second, while lower resolutions such as 720p and WD1 can reach up to 25fps (PAL) or 30fps (NTSC) depending on system configuration.

The recorder uses advanced video compression technologies including H.265 Pro+, H.265, H.264+ and H.264, which help reduce storage requirements while maintaining video quality. A dual stream system allows simultaneous high-quality recording and lower bandwidth remote viewing.

Audio recording is supported using G.711u compression with 64 Kbps audio bit rate, allowing video and audio to be recorded when compatible cameras are used.

The Prolux PXD-8204-HYK4MP is suitable for home, retail and small commercial CCTV systems, providing reliable video recording and efficient storage management for security monitoring applications.
