RG59 CCTV Cable 15m BNC Video with DC Power Shotgun Lead for Camera to DVR
SKU: RG59P-CABLE-15M
In Stock
Ready to ship • 125 available
Product Description
The RG59P-CABLE-15M is a 15m ready-assembled CCTV shotgun cable integrating RG59 75Ω coaxial video transmission with a parallel two-core DC power lead, enabling both video signal and 12V camera power to be delivered to a single CCTV camera from the DVR/NVR location using one cable run. Factory-crimped BNC male plugs on each RG59 end provide secure bayonet connections between the camera's BNC output and the recorder's BNC input, supporting standard analogue CVBS video as well as HD-TVI, AHD and CVI formats commonly used in hybrid DVR systems. The bundled DC power conductors terminate in a standard 2.1mm barrel plug at the camera end and either a matching 2.1mm socket or pre-stripped tails at the equipment end, allowing connection to centralised multi-channel 12VDC power supplies. This construction eliminates the need for separate video coax and power cable pulls, simplifying installation through walls, ceilings, trunking or external conduit while maintaining video integrity up to the RG59 specification limits (typically 200-300m for CVBS, 100-150m for HD formats depending on quality). The black PVC outer jacket provides mechanical protection and UV resistance for internal or sheltered external use, with the shotgun binding ensuring neat routing and reduced cable clutter at junction points. Moulded strain relief on all connectors enhances durability against repeated handling and environmental flexing typical in security installations. Deployed in small-to-medium CCTV systems, this 15m lead connects bullet, dome or turret cameras directly back to multi-channel DVRs, or serves as an extension from junction boxes to field cameras where central power distribution is implemented. It integrates with rack-mounted PSUs, patch panels and NVR enclosures, providing a complete video+power solution without baluns or additional adapters for coax-based systems.
